STXG-WELSX-SET

Stage Top Incubator for XY mechanical stage
For 100% CO2 gas cylinder use (with built-in digital gas mixer)

매뉴얼 다운로드 ( 영문 )

  • For manual/motor stage
  • With built-in digital gas mixer * For 100%CO2 gas cylinder use
  • Sample temperature：30 ~ 40℃ *With Real-time Sample Feedback Regulation
  • Includes Dish Attachments and Fixing Lids as standard (For 35mm dish, 60mm dish, slide glass/chamber slide/chambered coverglass）

Chamber：WELSX

  • Dimensions：W127.5 × D85 × H27mm
  • Weight：210 g
  • Water capacity：21 cc
    • Number of ports：4

Controller：STXG

  • Dimensions：W151×D263×H196 mm
  • Weight：3800 g
  • Maximum power consumption：100W
  • Temperature range：30-40℃ ＊room
  • temperature：25℃±2℃

Accessories

≪Dish Attachments≫　
・For 35/60mm dish【ATX-D】　
・For slide glass/chamber slide【ATX-CSG】　
・For ATX-D/ATX-CSG【ATX-A】　　

≪Dish Fixing Lids≫　
・For 35mm dish【LX-D35】　
・For 60mm dish【LX-D56】　
・For slide glass/chamber slide【LX-CSG】　　
・Feedback sensor【TSU-200F】　
・Sensor extension wire【HD2000】　
・Software【STX-APP】　
・USB cable　
・Gas tube　

Support Micrscope brand / Stage

[Required adapter]

Nikon

motorized：TI-S-E/ER［WELSX-TIM (optional)］
motorized：TI2-S-/SS-E SE-E［WELSX-TI2M (optional)］
Piezo：Nikon Piezo［WELSX-TIP (optional)］
manual：TI-SR/F SSR［WELSX-RA (optional)］
manual：TC-S-SR/SFR
manual：TS2-S-SM
mechanical：TI-SAMEVIDENT

Evident

motorized：IX3-SSU［WELSX-IX3 (optional)］
motorized：BX3-SSU［WELSX-SIG (optional)］
manual：IX3-SVR［WELSX-IX3 (optional)］
manual：IX3-SVL［WELSX-IX3 (optional)］
manual：GX-SVR［WELSX-SIG (optional)］
manual：GX-SFR［WELSX-SIG (optional)］
manual：IX2-SFR/SVR［WELSX-SIG (optional)］
mechanical：IX-MVR
mechanical：CKX3-MVR

Leica

motorized：DMI6000B Scanning stage 11522023［WELSX-K (optional)］
motorized：DMI8 Scanning stage［WELSX-K (optional)］
motorized：DMI8 3-plate stage［WELSX-K (optional)］
motorized：Leicamotorized：DMI8 Encoded stage［WELSX-K (optional)］manual：DMI8 3-plate stage［WELSX-K (optional)］
manual：DMI6000B 11522019［WELSX-K (optional)］

ZEISS

motorized：SCAN IM 120×100(Marzhauzer)［WELSX-K (optional)］
motorized：SCAN IM 130×85(Marzhauzer)［WELSX-K (optional)］manual：130×85 R/L［WELSX-K (optional)］

Prior
motorized：H117［WELSX-K (optional)］

PI
motorized：M-687［WELSX-K (optional)］

MARZHAUSER
motorized：SCAN IM 100×40［WELSX-K (optional)］
motorized：SCAN IM 112×74［WELSX-K (optional)］
motorized：SCAN IM 120×80［WELSX-K (optional)］
motorized：SCAN IM plus 120×80［WELSX-K (optional)］
motorized：SCAN　IM 120×88［WELSX-K (optional)］
motorized：SCAN IM 120×100［WELSX-K (optional)］
motorized：SCAN IM 127×83［WELSX-K(optional)]
motorized：SCAN IM 130×85［WELSX-K (optional)］
motorized：SCAN plus IM 130×85［WELSX-K (optional)］
motorized：SCAN IM 130×100［WELSX-K (optional)］

SIGMA
motorized：BIOS-Light［WELSX-K (optional)］
motorized：BIOS-406/206/106T ［WELSX-SIG (optional)］
motorized：BIOS-425/225/125/229T ［WELSX-K (optional)］

ASI
motorized：MS-2000（Flat Top）［WELSX-K (optional)］
Piezo：PZ2150/2300/2500(series)［WELSX-K (optional)］

LUDL
motorized：96S106［WELSX-K (optional)］

CHUO PRECISION
motorized：BIXY stage STD ［WELSX-K (optional)］
motorized：BIXY stage FFP ［WELSX-K (optional)］

Uncategorized

Profile

Profile of   Jin Jae-Hwan ( Instructor )

CEO of JNOPTIC co., ltd

2000년 06월05일 ~ 06월15일 ( OLYMPUS Japan in Tokyo)

Basic Knowledge of Microscope and Repair Training Course

2001년12월04일 ( OLYMPUS Japan in Tokyo)

Measuring Microscope Calibration License

Main Model: STM6

License ID Number: M029

2003년09월04일 ( OLYMPUS Japan in Tokyo)

Biological Confocal Microscope Setup & Service Training

Main Model: FluoView300 & FluoView500

2003년10월03일 ( OLYMPUS Japan in Tokyo)

Inverted Microscope  & Research Stereo Microscope Service Training

Main Model: IX71 / SZX9

2004년08월17일 ~ 8월20일 ( OLYMPUS Japan in Tokyo)

Confocal Microscope Setup & Service Training

Main Model:  FV1000

2004년 10월11 ~ 10월13일 ( OLYMPUS Japan in Tokyo)

Confocal Microscope Setup & Service Training

Main Model:  FV1000 M-COMB(Multi Combiner)

2005년06월20일 ~ 06월23일 ( OLYMPUS Japan in Tokyo)

Research System Microscope Service Training

 Main Model: AX70

2005년08월01일~08월02일 ( OLYMPUS Japan in Tokyo)

Polarizing Microscope Instruction Training

Main Model: BX51P

2005년12월19일 ~ 19일 ( OLYMPUS Japan in Tokyo)

ZDC Training for Maintenance &  Basic Knowledge of Confocal Microscope

2005년12월20일 ~ 22일 ( OLYMPUS Japan in Tokyo)

현미경의 성능을 끌어내는 Brushup Course (GA Academy)

2006년08월02일 ~ 08월04일 ( OLYMPUS Japan in Tokyo)

Confocal Laser Scanning Microscope for Industrial Market

D class License(for ols3000)

Main Model:  OLS 3000(Lext)

2006년10월11일 ~ 10월15일 ( OLYMPUS Japan in Tokyo)

Confocal Laser Scanning Microscope Training for Bio Maket

Maintenance Service Training

Main Mode :  M-COMB(Multi Combiner for FV1000)

2006년12월09일 IX Repair 교육

2007년05월07일 ~ 05월11일 ( OLYMPUS Japan in Tokyo)

Modify Training for Zero-Drift Compensation Unit of IX81

IX2-Customizing Training (Optic Port Modify)

Main Model: IX71 & IX81-ZDC

2007년09월03일 ~ 09월08일 ( OLYMPUS Japan in Tokyo)

Leicense D class Trainging

Main Model: OLYMPUS Bio Confocal Microscope  FV1000

2008년04월08일 ~ 04월10일 ( OLYMPUS Japan in INA_Nagano )

IV100 Setup Training

(in vivo fluorescence molecular imaging systems)

2008년07월22일 ~ 07월23일  ( Narishige Group in Tokyo,  Japan )

 Narishige Maintenance Training

2008년07월24일 ~ 07월28일 ( OLYMPUS Japan in Tokyo)

Research Inverted Microscope  maintenance Training

Main Model: IX81

2009년05월18일 ~ 5월22일 ( OLYMPUS Japan in Tokyo)

OLYMPUS Bio Confocal Microscope  License Training

 License Grade: FV1000 C class

2009년06월23일 ~ 06월26일 ( OLYMPUS Japan in Tokyo)

Confocal  Laser Scanning  Microscope  License Training

License Grade: FV10i  C class

2009년 10월19일 ~ 10월23일 ( OLYMPUS Japan in Tokyo )

Multi Photon Laser Scanning MICROSCOPE Setup Training

Main Model: MPE C class

2010년08월03일 ~ 08월08일 ( OLYMPUS Japan in Tokyo )

Modify Training for Zero-Drift Compensation Unit of IX81

Main Model: IX81-ZDC2

2011년 04월18일

Start a Business  – JNOpTIC co., LTD

2013년 04월4일

특허 출원: 현미경을 이용한 샘플의 높이 측정 방법

2014년 06월12일

특허 등록 ( 샘플의 높이 측정시 오차 보정 방법)

응용분야 : 현미경을 이용한 높이 측정

2021년 03월09일

특허등록 ( 현미경 샘플의 재치 방법을 통한 단면관찰 )

응용분야 : 연포장 샘플의 단면관찰, 모발의 단면 관찰, 그 외 각종 단면 관찰

2021년 06월25일

특허등록 ( 현미경 관찰법 – 동시 관찰법 )

응용분야 : 형광 관찰법과 명시야 관찰법의 동시 관찰이 가능하게 하여 빠른 수율 획득 가능

2023년 06월06일

JNO-ICG

동물 실험에서 실체 현미경으로 Indocyanine Green (ICG) 관찰을 위한 장비 개발 및 납품

(촬영된 결과 이미지는 JNO-ICG를 Click 하시면 확인 가능합니다.)

    260611_repair, Uncategorized

    Thermo Plate for Nikon

    TOKAI HIT Thermo Plate

    Clear Glass Heater For Nikon Microscope

    Olympus, Zeiss, Leica, Keyence 등 각종 메이커 가능합니다. 문의 바랍니다.

    온도 범위 : 상온 ~ 60 ℃ (TPi-UNIX 제외)

    “X”로 끝나는 모델은 강화 유리 적용 모델 입니다.

    (TPi-UNIX → 강화유리 적용 모델)

    공통 기본 구성품

    • Heating Plate
    • TPi Controller
    • Mounting Hook
    • Power code
    • AC Adapter
    • Temperature Sensor (TPiE 모델 제외)
    • Extension Wire (TPiE 모델 제외)
    • TEM Install CD&USB cable (TPiE 모델 제외)
    TPi Controller

    1. TPi-108RX

    Microscope: Nikon Ti2 / Ti / TE2000

    Applicable stage: Cross stage with 108 mm round opening

    • Setting range: ambient ~ 60℃
    • Plate dimension: φ108 mm
    • Heating area: W70 × D70 mm
    • Glass thickness: 0.5 mm

    2. TPi-TCSX

    Microscope: Nikon Ti2 / TS2R

    Applicable stage: XY Manual stage (TC-S-SR/SRF)

    • Setting range: ambient ~ 60℃
    • Plate dimension: W127.5 x D85.5 mm
    • Heating area: W115 × D75 mm
    • Glass thickness: 0.5 mm

    3. TPi-TIZGX

    Microscope: Nikon Ti2 / Ti

    Applicable stage: Nikon piezo stage

    By using optional Stage Adapter, the plate can be installed on motorized XY stage.

    ・TI2-NA (NIKON TI2-S-SE-E, TI2-S-SS-E)
    ・TID-NA (NIKON TI-S-E, TI-S-ER)

    • Setting range: ambient ~ 60℃
    • Plate dimension: W159.5 x D109.5 mm
    • Heating area: W129 × D87 mm
    • Glass thickness: 0.5 mm

    4. TPi-TS2X

    Microscope: Nikon TS2

    Applicable stage: Mechanical stage (TS2-S-SM)

    • Setting range: ambient ~ 60℃
    • Plate dimension: W238 x D112 mm
    • Heating area: W216 × D94 mm
    • Glass thickness: 0.5 mm

    5. TPi-TMSX

    Microscope: Nikon TMS / TMS-F

    Applicable stage: XY mechanical stage

    • Setting range: ambient ~ 60℃
    • Plate dimension: W130 x D90 mm
    • Heating area: W103 × D66 mm
    • Glass thickness: 0.5 mm

    6. TPi-TSX

    Microscope: Nikon TS / TS-100

    Applicable stage: XY mechanical stage

    • Setting range: ambient ~ 60℃
    • Plate dimension: W130 x D97.5 mm
    • Heating area: W101 × D71.5 mm
    • Glass thickness: 0.5 mm

    7. TPi-CKTS

    Microscope:  Nikon TS / TS-100 , Olympus  CKX41 / CKX31 / CK40 / CK30 / CK2

    Applicable stage: Nikon XY mechanical stage TE/TI-SAM , Olympus XY mechanical stage IX-MVR

    • Setting range: ambient ~ 60℃
    • Plate dimension: W150 x D117 mm
    • Heating area: W131 × D95 mm
    • Glass thickness: 1.0 mm

    8. TPi-SX

    Microscope: Upright Microscopes Ni / Ci / 90i / 80i / 55i / 50i E1000 / E800 / E600 / E400 / E200 OPTIPHOT-2 / LABOPHOT-2

    Applicable stage: Mechanical stage for upright microscopes

    (제공된 마운팅 플레이트를 사용하면 쉽게 부착할수 있습니다)

    • Setting range: ambient ~ 60℃
    • Plate dimension: W142 x D115 mm
    • Heating area: W128 × D95 mm
    • Glass thickness: 0.5 mm

    9. TPi-SMZ25X

    Microscope:  Nikon SMZ25 / SMZ18 / SMZ1270

    Applicable illumination base:  P2-PB/ P2-DBL / P-DFB, P-DSL32 / P-DSF32

    • Setting range: ambient ~ 60℃
    • Plate dimension: W251 x D238 mm
    • Heating area: W185 × D175 mm
    • Glass thickness: 1.0 mm

    10. TPi-SMZSLX

    Microscope:  Nikon SMZ1500 / SMZ1000 / SMZ800

    Applicable illumination stand:  C-DSD / C-DSS / C-BD

    • Setting range: ambient ~ 60℃
    • Plate dimension: W254 x D263 mm
    • Heating area: W175 × D185 mm
    • Glass thickness: 1.0 mm

    11. TPi-SMZSSX

    Microscope:  Nikon SMZ1500 / SMZ 1000 / SMZ 800

    Applicable illumination base: C-PS, C-DS

    • Setting range: ambient ~ 60℃
    • Plate dimension: W198 x D269 mm
    • Heating area: W162 × D152 mm
    • Glass thickness: 1.0 mm

    12. TPi-SMZR

    Microscope:   Nikon SMZ1500 / SMZ1000 / SMZ800

    Applicable illumination stand:  C-PS, C-05

    • Setting range: ambient ~ 60℃
    • Plate dimension: φ 180
    • Heating area: W120 × D120 mm
    • Glass thickness: 1.0 mm

    13. TPi-SMZU / TPi-SMZ6 / TPi-SMZ

    Microscope:   Nikon SMZ Series

    Applicable illumination stand:  Nikon SMZ illumination base

    SMZ-U1/U2/U3/U4/10A-3/10A-5/660/645/2T/2B/1/1B

    • Setting range: ambient ~ 60℃
    • Plate dimension: W132 x D195 mm(SMZ) / W200 x D240 mm(SMZ6) / W260 x D225 mm(SMZU)
    • Glass thickness: 1.0 mm

    14. TPi-UNIX

    Universal Type for Stereo Microscope

    For Various types of illumination base

    • Setting range: ambient ~ 50℃
    • Plate dimension: W435 x D220 mm
    • Legs adjustable range : 75~100mm
    • Heating area: W400 × D175 mm
    • Glass thickness: 1.5 mm

    15. TPi-W / TPi-WL

    Universal Large Type (W230 x D180 / W310 x D220)

    • Setting range: ambient ~ 60℃
    • Plate dimension: W230 x D180 / W310 x D220 mm
    • Heating area: W180 × D140 / W250 x D170 mm
    • Glass thickness: 1.5 mm

    16. TPiD-VITX

    Universal Type for stereo microscopes

    For Thawing Process of Frozen embryo

    2ch controller
    • Setting range: ambient ~ 60℃
    • Base dimentions：W435 × D280 mm
    • Plate dimentions： W230 × D148 mm
    • Legs adjustable range：75 – 100 mm
    • Heating area：W95 × D128 × 2 pcs
    • Glass thickness：0.5 mm
    TOKAI HIT Tpi series Instruduction manual다운로드

    Thermo Plate / Thermo Stage / Warming Plate / Heating Plate / Heating Stage / 가열 스테이지

    260611_repair, Uncategorized

    Thermo Plate for Evident

    TOKAI HIT Thermo Plate

    Clear Glass Heater For Olympus

    Nikon, Zeiss, Leica, Keyence 등 각종 메이커 가능합니다. 문의 바랍니다.

    온도 범위 : 상온 ~ 60 ℃ (TPi-UNIX 제외)

    “X”로 끝나는 모델은 강화 유리 적용 모델 입니다.

    (TPi-UNIX → 강화유리 적용 모델)

    공통 기본 구성품

    • Heating Plate
    • TPi Controller
    • Mounting Hook
    • Power code
    • AC Adapter
    • Temperature Sensor (TPiE 모델 제외)
    • Extension Wire (TPiE 모델 제외)
    • TEM Install CD&USB cable (TPiE 모델 제외)
    TPi Controller

    1. TPi-110RX

    TPi-110RX Mady by Tokai-Hit

    Microscope: Olympus IX83 / IX 73 / IX81 / IX71 /IX 51 / IX70/ IX50, IMT2

    Applicable stage: Cross stage with 110 mm round opening

    • Setting range: ambient ~ 60℃
    • Plate dimension: φ110 mm
    • Heating area: W70 × D70 mm
    • Glass thickness: 0.5 mm

    2. TPi-110R13

    TPi-110RX Mady by Tokai-Hit

    Microscope: Olympus IX83 / IX 73 / IX81 / IX71 /IX 51 / IX70/ IX50, IMT2

    Applicable stage: Cross stage with 110 mm round opening

    • Setting range: ambient ~ 60℃
    • Plate dimension: φ110 mm
    • Heating area: W70 × D70 mm
    • Glass thickness: 1.3 mm
    • Ideal for relief contrast observation with a glass bottom dish

    3. TPi-IX3X

    Microscope: Olympus IX83 / IX 73

    Applicable stage: XY manual (IX3-SVR)/XY motorized (IX3-SSU) stage

    • Setting range: ambient ~ 60℃
    • Plate dimension: W189.5 x D155.5 mm
    • Heating area: W174 × D127 mm
    • Glass thickness: 0.5 mm

    4. TPi-IX3-13

    Microscope: Olympus IX83 / IX 73

    Applicable stage: XY manual (IX3-SVR)/XY motorized (IX3-SSU) stage

    • Setting range: ambient ~ 60℃
    • Plate dimension: W189.5 x D155.5 mm
    • Heating area: W155 × D130 mm
    • Glass thickness: 1.3 mm

    5. TPi-SQX

    Microscope: Olympus IX series

    Applicable stage: manual/motorized XY stage with 160 × 110 mm aperture for Prior Scientific stage H117

    아래 아답타를 사용하여 다양한 스테이지에 설치 가능

    • MK-IX3 (OLYMPUS IX3-SSU, IX3-SVR）
    • MK-SIG (OLYMPUS BX3-SSU, IX2-SFR, IX2-SVL2)
    • TI2-ZILCS (NIKON TI2-S-SE-E, TI2-S-SS-E)
    • TI2-RA (NIKON TC-S-SR, TC-S-SRF)
    • TID-ZILCS (NIKON TI-S-E, TI-S-ER)
    • MK-RA (NIKON TI-SR, TI-SSR)
    • MK-EVOS (Thermo Fisher Scientific EVOS FL)
    • MK-EVOS-AT (Thermo Fisher Scientific EVOS FL Auto)
    • Setting range: ambient ~ 60℃
    • Plate dimension: W160 x D110 mm
    • Heating area: W128 × D84 mm
    • Glass thickness: 0.5 mm

    6. TPi-CKX53X

    Microscope: Olympus CKX53 series

    Applicable stage: XY mechanical stage CKX3-MVR

    • Setting range: ambient ~ 60℃
    • Plate dimension: W190 x D138 mm
    • Heating area: W174 × D127 mm
    • Glass thickness: 0.5 mm

    7. TPi-CKX

    Microscope: Olympus  CKX41 / CKX31 / CK40 / CK30 / CK2

    Applicable stage: Olympus XY mechanical stage IX-MVR

    • Setting range: ambient ~ 60℃
    • Plate dimension: W127 x D85 mm
    • Heating area: W103 × D63 mm
    • Glass thickness: 0.5 mm

    8. TPi-CKTS

    Microscope: Olympus  CKX41 / CKX31, CK40 / CK30 / CK2 Nikon TS / TS-100

    Applicable stage: Olympus XY mechanical stage IX-MVR, Nikon XY mechanical stage TE/TI-SAM

    • Setting range: ambient ~ 60℃
    • Plate dimension: W150 x D117 mm
    • Heating area: W131 × D95 mm
    • Glass thickness: 0.5 mm

    9. TPi-SX

    Tokai-Hit TPi-SX Themo Plate

    Microscope: Upright Microscopes BX53 / BX43 / CX40 / CH40 / CH30

    Applicable stage: Mechanical stage for upright microscopes

    • Setting range: ambient ~ 60℃
    • Plate dimension: W142 x D115 mm
    • Heating area: W128 × D95 mm
    • Glass thickness: 0.5 mm

    10. TPi-SZX2X

    Microscope: Olympus SZX16 / SZX10

    Applicable illumination base: SZX2-ILLB / SZX2–ILLD / SZX2- ILLK / SZX2- ILLT / SZX2- ILLTQ / SZX2- ILLTS

    • Setting range: ambient ~ 60℃
    • Plate dimension: W238 x D227 mm
    • Heating area: W162 × D152 mm
    • Glass thickness: 1.0 mm

    11. TPi-SZX1

    Microscope: Olympus MVX10 SZX12 / SZX9 / SZX7

    Applicable illumination stand: SZX-ILLK / SZX-ILLB2 / SZX-ILLD2

    • Setting range: ambient ~ 60℃
    • Plate dimension: W205 x D205 mm
    • Heating area: W170 × D170 mm
    • Glass thickness: 1.0 mm

    12. TPi-SZ2

    Microscope: Olympus　SZX7, SZ61

    Applicable illumination base: SZ2-ST + SZ2-ILA

    • Setting range: ambient ~ 60℃
    • Plate dimension: W278 x D175 mm
    • Heating area: W230 × D146 mm
    • Glass thickness: 1.0 mm

    13. TPi-OZX

    Microscope: Olympus SZ60 / SZ40 / SZ11

    Applicable illumination stand: OLYMPUS SZ60 / SZ40 / SZ11 illumination stand

    • Setting range: ambient ~ 60℃
    • Plate dimension: W180 x D230 mm
    • Heating area: W162 × D152 mm
    • Glass thickness: 1.0 mm

    14. TPi-UNIX

    Universal Type for Stereo Microscope

    For Various types of illumination base

    • Setting range: ambient ~ 50℃
    • Plate dimension: W435 x D220 mm
    • Legs adjustable range : 75~100mm
    • Heating area: W400 × D175 mm
    • Glass thickness: 1.5 mm

    15. TPi-W / TPi-WL

    Tokai-Hit TPi-WL Themo Plate

    Universal Large Type TPi-W (W230 x D180 / W180 x D140)
    Universal Large Type TPi-WL (W310 x D220 / W250 x D170)

    • Setting range: ambient ~ 60℃
    • Glass thickness: 1.5 mm

    16. TPiD-SZX2DX

    Tokai-Hit TPiD-SZX2DX Themo Plate

    Entire Surface Heating Plate for Olympus SZX16/10
    – SZX2-ILLB/ILLD/ILLK/ILLT/ILLTQ/ILLTS

    • Setting range: ambient ~ 50℃
    • Dimensions：W357×D243 mm
    • Heating area：(Glass part)：W128×D95 mm
    • Glass thickness：0.5 mm

    17. TPiD-VITX

    Universal Type for stereo microscopes

    For Thawing Process of Frozen embryo

    2ch controller
    • Setting range: ambient ~ 60℃
    • Base dimentions：W435 × D280 mm
    • Plate dimentions： W230 × D148 mm
    • Legs adjustable range：75 – 100 mm
    • Heating area：W95 × D128 × 2 pcs
    • Glass thickness：0.5 mm
    TOKAI HIT Tpi series Instruduction manual다운로드

    Thermo Plate / Thermo Stage / Warming Plate / Heating Plate / Heating Stage / 가열 스테이지

    Uncategorized

    Thermo plate

    TOKAI HIT Thermo Plate Clear Glass Heater

    현미경 관찰하는 동안 시료의 정확하고 안정적인 열 제어 보장.

    생명공학분야에서 산업분야에 이르기까지 다양한 종류의 온도 제어.

    TPi 시리즈는 이전 버전에 비해 탁월한 성능과 새로운 기능으로 설계된 제품입니다

    Tokai Hit
    Thermo Plate for microscopy
    • Stereo, Uplight, Inverted Microscope에 장착하여 정확한 온도조절 가능
    • 강화유리 장착으로 다양한 실험에서도 무리 없이 사용 가능
    • 강화유리 10년 무상 보증
    • Plate에 Green LED장착으로 최적의 온도 상태 표시.
    • 유리 전체에서 균일하게 가열할 수 있는 특허기술로 샘플전체에 일정한  온도 조절 가능
    • Nikon, Olympus, Leica, ZEISS에 맞는 제품 공급 가능

    Standard Type(Glass Heater) 제품의 특징

    • 강화유리 적용으로 파손에 대한 걱정이 없습니다
    Tokai Hit

    TPi 시리즈 Thermoplate의 70% 이상이 강화유리 히터를 사용하며 Glass 파손에 대한 10년 무상 수리 서비스를 제공 합니다.

    참고: 모델명이 “X”로 끝나는 모델이 강화 유리 적용 모델 입니다. (TPi-UNIX → 강화유리 적용 모델)

    • LED 표시장치
    Tokai Hit
    • Compact한 디자인과 손쉬운 설치
    Tokai Hit

    작고 가벼운 설계로 되었으며, Muli-Functional 시스템은 다양한 분야에서 정확한 온도 조절을 제공 합니다.

    • 쉬운 온도 측정
    Tokai Hit

    멸균센서를 사용하여 샘플의 실제온도 또는 플레이트 표면의 온도를 측정 할 수 있습니다.

    • 온도 관리 프로그램 TEM
    Tokai Hit

    플레이트 표면의 온도, 설정값 및 외부 온도 센서를 모니터링.

    CVS 형식으로 저장가능.

    Thermo Plate TPi 시리즈 기본 제공.

    • 원터치 온도 보정
    Tokai Hit

    실내 온도에서 시스템의 온도를 재 보정 할 수 있습니다.

    출하시 실내온도 37℃ 에서 출하시 25 ℃ ± 2 ℃ 로 설정 되어있습니다.

    • 균일한 온도 전달
    Tokai Hit

    Thermo Plate / Thermo Stage / Warming Plate / Heating Plate / Heating Stage / 가열 스테이지
